Power Conversion Solutions
| Management: | Unmanaged |
| Ports: | 2 x 10/100/1000M Copper + PoE 2 x 10/100/1000M Copper |
| Connectors: | Power: D38999 LAN: D38999 |
| Designed to Meet: | MIL-STD-1275 | MIL-STD-704 | MIL-STD-810 | MIL-STD-461 | IP67 |
| Dimensions: | 6.5" X 5.71" X 2.17"165mm X 145mm X 55mm |
| Weight: | 28.22oz800g |
| Operating Temp.: | -40°C to 85°C |
| Power input: | 24VDC (16 - 50VDC), 160W |
| Power output: | 48VDC, 2A per port |
| Special Features: | PoE |
For all your requirements, we’ll custom design a solution to fit your needs
CONTACT US TODAY
All of our products can be configured to your specific requirements. Customers are invited to work with a design engineer to define the output, input range, protection limits and dimensions of the power solution which best meets their project needs. This can frequently be accomplished without NRE. Use the contact form to submit a request, or contact us to discuss your requirements. For our US team call (603) 267-8865, for our European team call: +49 42-61 9429979. Configurations created for specific requirements will be assigned a new variant part number.
All our power and networking solutions are configurable. Work directly with our experienced engineers to tailor one of our mature designs – power input & output range, voltage & current levels, connector style, number of ports, form factor, additional compute hosting, MIL-STD compliance, and much more – our team can create a power or networking solution for your unique application with minimal or no NRE investment.
We are also experienced in developing custom solutions from specifications, addressing unique design challenges - saving you platform space, integration risk, and development time.
|
