Field-Proven
Military Power Solutions
Rapidly Tailorable
to Your Needs products

Performance. Reliability. Safety.

mots

Modified Off The Shelf Solutions

Why Choose a MOTS Solution?

  • Rapidly Configurable
  • No NRE Investment
  • Scalable Quantities
  • Reduced Cost and Lead Time
    vs. Custom Designs
  • Low Risk Starting Point
  • Application-Specific for
    Enhanced Performance

Contact Us

Get Started With One of Hundreds of Mature Designs

Filter products
Categories
Category filters
No filters for this category
Voltage:
All Input voltage range 12V - 70V Input voltage range 220V - 350V
# of Outputs:
All One Two Three Four Five Six Seven Eight Nine Ten
Phase:
All Single Phase Three Phase
# of Outputs:
All One Two Three Four Five
Input:
All AC DC
Type:
All Power Supply Holdup Unit
DC-DC Power Supplies
Baseplate Mount
Input voltage range 12V - 70V
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M741950W2.35" X 2" X 0.49"59.69mm X 50.8mm X 12.45mm28V
1.8V - 50V
10A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M700975W3.26" X 1.83" X 0.72"82.8mm X 46.48mm X 18.29mm28V
3.3V - 56V
10A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7019100W3.26" X 1.83" X 0.72"82.8mm X 46.48mm X 18.29mm28V
3.3V - 56V
15A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7420100W2.95" X 1.77" X 0.61"75mm X 45mm X 15.5mm28V
3.3V - 50V
10A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M6211200W4.38" X 2.76" X 0.61"111.25mm X 70.1mm X 15.49mm28V
1.5V - 28V
40A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M6212200W5.18" X 2.76" X 0.73"131.45mm X 70mm X 18.49mm28V
1.5V - 28V
40A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7017200W5.32" X 2.76" X 0.81"135mm X 70.1mm X 20.57mm28V
1.5V - 60V
15A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7028200W4.14" X 2.56" X 0.55"105.16mm X 65.02mm X 13.97mm28V
3.3V - 50V
20A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7128200W4.38" X 2.6" X 0.55"111.25mm X 66.04mm X 13.97mm28V  MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7228200W4.38" X 2.76" X 0.61"111.2mm X 70mm X 15.49mm28V
2V - 15V
50A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7318200W4.2" X 2.5" X 0.5"106.68mm X 63.5mm X 12.7mm28V
3.3V - 50V
18A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7719200W3.26" X 1.83" X 0.72"82.8mm X 46.48mm X 18.29mm28V
12V - 28V
10A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M7029300W3.75" X 2.76" X 0.81"95.25mm X 70.1mm X 20.57mm28V
5V - 50V
20A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7429300W10.63" X 5.91" X 2.4"270mm X 150mm X 61mm28DCV
18V - 50V
 MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7729400W3.27" X 3.23" X 0.8"83.06mm X 82.04mm X 20.32mm28V
18V - 50V
20A
MIL-STD-810, MIL-STD-461
M4244500W6.5" X 4.5" X 0.85"165.1mm X 114.3mm X 21.59mm28V
3.3V - 400V
30A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M6500500W5.4" X 3.1" X 0.67"137.16mm X 78.74mm X 17.02mm28V
3.3V - 28V
70A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7027500W5.31" X 2.76" X 0.81"134.87mm X 70.1mm X 20.57mm28V
5V - 50V
40A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7127500W5.91" X 2.76" X 0.81"150.11mm X 70.1mm X 20.57mm28V
5V - 50V
40A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7325500W4.6" X 3.6" X 0.8"116.84mm X 91.44mm X 20.32mm28V
3.3V - 50V
21A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7727500W5.31" X 2.76" X 0.81"134.87mm X 70.1mm X 20.57mm28V
12V - 50V
40A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7425800W6.24" X 4.64" X 1.15"158.5mm X 117.86mm X 29.21mm28V
3.3V - 50V
50A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7525800W6.24" X 4.64" X 1.15"158.5mm X 117.86mm X 29.21mm28V
3.3V - 50V
50A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M75281000W6.4" X 4.76" X 1.29"162.5mm X 120.8mm X 32.7mm28V
12V - 50V
50A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M75291000W10.63" X 5.91" X 2.4"270mm X 150mm X 61mm28V
12V - 48V
 MIL-STD-704, MIL-STD-810, MIL-STD-461
Two Outputs
M278630W2.35" X 2" X 0.49"59.69mm X 50.8mm X 12.45mm28V
#1:2.5V - 28V
#2:2.5V - 28V
#1:3A
#2:3A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M71260W2.95" X 2.95" X 0.71"74.93mm X 74.93mm X 18.03mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#1:5A
#2:5A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M872780W2.6" X 3.75" X 0.5"66.04mm X 95.25mm X 12.7mm28V
#1:1.5V - 70V
#2:1.5V - 70V
#1:10A
#2:10A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8053125W5.06" X 2.7" X 0.61"128.52mm X 68.58mm X 15.49mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#1:10A
#2:10A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8253200W5.4" X 3.1" X 0.61"137.16mm X 78.74mm X 15.49mm28V
#1:2.5V - 50V
#2:2.5V - 50V
#1:12A
#2:12A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8254200W5.51" X 3.09" X 1"140mm X 78.51mm X 25.4mm28V
#1:3.3V - 48V
#2:3.3V - 48V
#1:18A
#2:12A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Three Outputs
M873750W2.2" X 3.75" X 0.5"55.88mm X 95.25mm X 12.7mm28V
#1:1.8V - 70V
#2:2.5V - 24V
#3:2.5V - 24V
#1:10A
#2:2.5A
#3:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
813960W2.16" X 3.1" X 0.5"54.86mm X 78.74mm X 12.7mm28V
#1:1V - 15V
#2:1.8V - 24V
#3:1.8V - 24V
#1:8A
#2:3A
#3:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8337125W4.73" X 3.54" X 0.61"120.14mm X 89.92mm X 15.49mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#3:7V - 28V
#1:10A
#2:6A
#3:6A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8637125W4.53" X 3.54" X 0.61"115.06mm X 89.92mm X 15.49mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#3:7V - 28V
#1:10A
#2:6A
#3:6A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M7338600W6.5" X 4.75" X 0.7"165.1mm X 120.65mm X 17.78mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 50V
#1:16A
#2:16A
#3:16A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Four Outputs
M71460W2.95" X 2.95" X 0.92"74.93mm X 74.93mm X 23.37mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 28V
#4:1.8V - 28V
#1:5A
#2:5A
#3:2A
#4:2A
MIL-STD-1275, MIL-STD-704, MIL-STD-810
M814960W2.16" X 3.1" X 0.5"54.86mm X 78.74mm X 12.7mm28V
#1:2.5V - 28V
#2:1.8V - 24V
#3:1.8V - 24V
#4:1.8V - 24V
#1:1.5A
#2:3A
#3:1.25A
#4:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M834960W3.65" X 2.16" X 0.5"92.71mm X 54.86mm X 12.7mm28V
#1:5V
#2:5V
#3:15V
#4:15V
#1:1A
#2:1A
#3:0.5A
#4:0.5A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8747100W2.75" X 4.4" X 0.5"69.85mm X 111.76mm X 12.7mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 24V
#4:1.8V - 24V
#1:16A
#2:10A
#3:1.25A
#4:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8647125W4.53" X 3.9" X 0.61"115.06mm X 99.06mm X 15.49mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#3:3.3V - 28V
#4:3.3V - 30V
#1:12A
#2:6A
#3:6A
#4:3A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8453150W5.5" X 3.25" X 0.61"139.7mm X 82.55mm X 15.49mm28V
#1:2.5V - 50V
#2:2.5V - 50V
#3:1.24V - 26V
#4:1.24V - 26V
#1:20A
#2:20A
#3:1.25A
#4:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8696200W6.99" X 3.19" X 1.1"177.6mm X 81.08mm X 27.94mm28V
12V - 48V
10.5V-36V / 18V-48VA
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Five Outputs
M8757100W2.75" X 4.49" X 0.5"69.85mm X 114.05mm X 12.7mm28V
#1:1V - 50V
#2:1.8V - 24V
#3:1.8V - 24V
#4:1.8V - 24V
#5:2.5V - 24V
#1:20A
#2:3A
#3:3A
#4:1.25A
#5:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8657125W4.92" X 3.9" X 0.61"124.97mm X 99.06mm X 15.49mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#3:3.3V - 28V
#4:3.3V - 28V
#5:3.3V - 24V
#1:6A
#2:6A
#3:6A
#4:3A
#5:1.5A
MIL-STD-1275, MIL-STD-704, MIL-STD-461
Six Outputs
M876780W2.5" X 3.9" X 0.5"63.5mm X 99.06mm X 12.7mm28V
#1:5V - 28V
#2:1.8V - 24V
#3:1.8V - 24V
#4:1.8V - 24V
#5:1.8V - 24V
#6:1.8V - 24V
#1:1A
#2:1.25A
#3:3A
#4:1.25A
#5:1.25A
#6:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8667125W4.92" X 3.9" X 0.61"124.97mm X 99.06mm X 15.49mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#3:3.3V - 28V
#4:3.3V - 28V
#5:3.3V - 24V
#6:3.3V - 24V
#1:6A
#2:6A
#3:6A
#4:3A
#5:1.25A
#6:1.25A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M1132320W6.22" X 3.74" X 1"158mm X 95mm X 25.4mm28V
#1:3.3V - 12V
#2:3.3V - 6V
#3:3.3V - 6V
#4:-20V - -3.3V
#5:2V - 2.5V
#6:10V - 28V
#1:10A
#2:30A
#3:15A
#4:4A
#5:2A
#6:0.65A
MIL-STD-704, MIL-STD-810, MIL-STD-461
Eight Outputs
M810880W3.07" X 2.17" X 0.57"78mm X 55mm X 14.5mm28V  MIL-STD-1275, MIL-STD-704, MIL-STD-461
M802145W5.1" X 4.1" X 0.61"129.54mm X 104.14mm X 15.49mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 50V
#4:1.8V - 28V
#5:1.8V - 28V
#6:1.8V - 50V
#7:1.8V - 50V
#8:1.8V - 50V
#1:6A
#2:6A
#3:6A
#4:9A
#5:9A
#6:6A
#7:2A
#8:2A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M811145W6.5" X 3.3" X 0.61"165.1mm X 83.82mm X 15.49mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 50V
#4:1.8V - 50V
#5:1.8V - 50V
#6:1.8V - 50V
#7:1.8V - 50V
#8:1.8V - 50V
#1:2A
#2:3A
#3:3A
#4:5A
#5:8A
#6:4A
#7:2A
#8:2A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M814145W6.5" X 3.3" X 0.61"165.1mm X 83.82mm X 15.49mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 50V
#4:1.8V - 28V
#5:1.8V - 28V
#6:1.8V - 50V
#7:1.8V - 50V
#8:1.8V - 50V
#1:12A
#2:6A
#3:6A
#4:3A
#5:3A
#6:3A
#7:3A
#8:3A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Nine Outputs
M635250W7.85" X 4.37" X 0.81"199.39mm X 111mm X 20.57mm28V
#1:3.3V - 28V
#2:3.3V - 28V
#3:3.3V - 28V
#4:3.3V - 28V
#5:3.3V - 28V
#6:3.3V - 50V
#7:1.8V - 50V
#8:1.8V - 50V
#9:1.8V - 50V
#1:10A
#2:5A
#3:5A
#4:5A
#5:5A
#6:5A
#7:5A
#8:5A
#9:5A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M641250W8" X 4.72" X 0.81"203.2mm X 119.89mm X 20.5mm28V  MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Ten Outputs
M8110150W5.1" X 4.1" X 0.61"129.54mm X 104.14mm X 15.49mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#3:1.8V - 50V
#4:1.8V - 50V
#5:1.8V - 50V
#6:3.3V - 50V
#7:1.8V - 50V
#8:1.8V - 50V
#9:1.8V - 50V
#10:1.8V - 50V
#1:2A
#2:5A
#3:5A
#4:2.5A
#5:2.5A
#6:0.7A
#7:2.5A
#8:5A
#9:2A
#10:2A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Input voltage range 220V - 350V
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M6201200W4.14" X 2.77" X 0.61"105.16mm X 70.36mm X 15.49mm270V
1.8V - 60V
36A
MIL-STD-810, MIL-STD-461
M7429300W10.63" X 5.91" X 2.4"270mm X 150mm X 61mm28DCV
18V - 50V
 MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M6204400W5.4" X 3.5" X 0.75"137.16mm X 88.9mm X 19.05mm270V
1.8V - 28V
50A
MIL-STD-810, MIL-STD-461
M6203500W5.91" X 2.56" X 0.76"150.11mm X 65.02mm X 19.3mm270V
3.3V - 50V
30A
MIL-STD-810, MIL-STD-461
M81831000W6.44" X 3.7" X 1.5"163.58mm X 93.98mm X 38.1mm270V
5V - 50V
42A
MIL-STD-810, MIL-STD-461
M81862000W6.9" X 5.81" X 1.6"175.26mm X 147.57mm X 40.64mm270V
5V - 60V
80A
MIL-STD-810, MIL-STD-461
M81872000W7.65" X 5.81" X 1.6"194.31mm X 147.57mm X 40.64mm270V
5V - 60V
80A
MIL-STD-810, MIL-STD-461
PCB Mount
Input voltage range 12V - 70V
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M711715W2.17" X 1.18" X 0.48"55mm X 30mm X 12.3mm28V
2.5V - 28V
4A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M78525W1.99" X 1.99" X 0.49"50.5mm X 50.5mm X 12.5mm28V  MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M711950W1.99" X 1.99" X 0.49"50.5mm X 50.5mm X 12.5mm28V
2.5V - 50V
8A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Two Outputs
M78786W1.38" X 1.38" X 0.49"35mm X 35mm X 12.5mm28V
#1:3.3V - 15V
#2:3.3V - 15V
#1:0.25A
#2:0.25A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M78796W1.97" X 1.02" X 0.49"50mm X 26mm X 12.5mm28V
#1:3.3V - 15V
#2:3.3V - 15V
#1:0.25A
#2:0.25A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M711520W2.48" X 1.18" X 0.59"63mm X 30mm X 15mm28V
#1:1.5V - 48V
#2:1.5V - 48V
#1:3A
#2:1.5A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M78630W1.99" X 1.99" X 0.49"50.5mm X 50.5mm X 12.5mm28V
#1:1.8V - 50V
#2:1.8V - 50V
#1:4A
#2:4A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M8263150W5" X 1.81" X 0.87"127mm X 46mm X 22mm28V
#1:3.3V - 12V
#2:1.2V - 5.5V
#1:10A
#2:10A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Three Outputs
M64720W2.56" X 1.99" X 0.51"65.02mm X 50.55mm X 12.95mm28V
#1:2.5V - 28V
#2:2.5V - 28V
#3:2.5V - 28V
#1:2A
#2:2A
#3:2A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Four Outputs
M797140W2.56" X 2.07" X 0.63"65mm X 52.5mm X 16mm28V  MIL-STD-810, MIL-STD-461
M787450W2.95" X 2.6" X 0.52"74.9mm X 66mm X 13.1mm28V
#1:1.8V - 28V
#2:1.8V - 28V
#3:1.8V - 50V
#4:3.3V - 24V
#1:5A
#2:5A
#3:3A
#4:1.25A
MIL-STD-810, MIL-STD-461
Five Outputs
M715530W2.36" X 1.18" X 0.49"59.99mm X 30mm X 12.45mm28V  MIL-STD-810, MIL-STD-461
M715930W2.4" X 1.3" X 0.39"60.96mm X 33.02mm X 9.91mm28V
#1:5V - 15V
#2:1V - 3.3V
#3:3.3V - 24V
#4:3.3V - 24V
#5:3.3V - 24V
#1:3A
#2:3A
#3:0.4A
#4:0.4A
#5:0.4A
MIL-STD-810
VPX 3U
Input voltage range 220V - 350V
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Two Outputs
M4096800W3U, 1"3U, 1"270V
3.3V - 12V
30A
MIL-STD-704, MIL-STD-810
VPX 6U
DC-DC Holdup Units
Baseplate Mount
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M1255 W2.56" X 2.15" X 0.63"65mm X 54.6mm X 16mm28V
18V - 48V
12A
MIL-STD-1275, MIL-STD-810, MIL-STD-461
M255 2.15" X 2.56" X 0.55"54.61mm X 65.02mm X 13.97mm28V
18V - 48V
12A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M2501.5J3.7" X 2.56" X 0.55"93.98mm X 65.02mm X 13.97mm28V
18V - 48V
12A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M2567J4.53" X 4.72" X 0.55"115mm X 120mm X 14mm28V
18V - 48V
12A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
VPX 3U
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M416248J3U, 1"3U, 1"28V
1V - 85V
 MIL-STD-704, MIL-STD-810, MIL-STD-461
M4262800W3U, 0.97"3U, 0.97"270V
270V
A
MIL-STD-704, MIL-STD-461
AC-DC Power Supplies
Free Air Convection Cooled
Single Phase Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M13261000W12" X 9" X 10.5"304.8mm X 228.6mm X 266.7mm115/230V 1Ø
3.3V - 300V
80A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M66202500W18.71" X 7.48" X 7.32"475.15mm X 190mm X 186mm85ac~264acV 1Ø
23V - 31V
50A
MIL-STD-704, MIL-STD-810, MIL-STD-461
Baseplate Mount
Single Phase Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M911150W6.3" X 3.15" X 1.77"160mm X 80mm X 45mm115V 1Ø
3.3V - 24V
0 to 15AA
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461
M1981200W6.2" X 4.6" X 0.79"157.48mm X 116.84mm X 20.07mm115/230V 1Ø
3.3V - 48V
20A
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461
M1982300W7" X 4.7" X 0.85"177.8mm X 119.38mm X 21.59mm115/230V 1Ø
3.3V - 48V
20A
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461
M1986300W6.99" X 4.7" X 1.18"177.6mm X 119.4mm X 30mm115/230V 1Ø
24V - 50V
12.5A
MIL-STD-1399, MIL-STD-810, MIL-STD-461, IEC 62368-1
M3916500W5" X 8" X 1.18"127mm X 203.2mm X 29.97mm115V 1Ø
24V - 50V
20A
MIL-STD-1399, MIL-STD-810, MIL-STD-461, IEC 62368-1
M916500W8" X 5" X 0.9"203.2mm X 127mm X 22.86mm115/230V 1Ø
3.3V - 300V
50A
MIL-STD-810, MIL-STD-461
M1091000W9.84" X 5.5" X 1"249.94mm X 139.7mm X 25.4mm115V 1Ø
5V - 60V
80A
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461
M1691000W9.84" X 5.51" X 1.5"249.94mm X 139.95mm X 38.1mm115/230V 1Ø
3.3V - 300V
80A
MIL-STD-810, MIL-STD-461
M31691000W11" X 7.25" X 3.1"279.4mm X 184.15mm X 78.74mm115V 1Ø
5V - 270V
36A
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461
M61691000W11" X 7.25" X 3.1"279.4mm X 184.15mm X 78.74mm115/230V 1Ø
5V - 48V
42A
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461
Two Outputs
M1912300W4.7" X 7" X 1.18"119.4mm X 177.8mm X 30mm115/230V 1Ø
#1:12V - 48V
#2:3.3V - 12V
#1:20A
#2:5A
MIL-STD-704, MIL-STD-1399, MIL-STD-810, MIL-STD-461, IEC 62368-1
Three Outputs
M1963130W5.19" X 3.7" X 0.79"131.83mm X 93.98mm X 20.07mm115/230V 1Ø
#1:0.8V - 40V
#2:0.8V - 40V
#3:0.6V - 5V
#1:5A
#2:5A
#3:8A
MIL-STD-810, MIL-STD-461
M1965130W5.19" X 4" X 0.79"131.93mm X 101.6mm X 20.07mm115/230V 1Ø
#1:0.8V - 12V
#2:0.8V - 12V
#3:0.6V - 5V
#1:5A
#2:5A
#3:5A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
Four Outputs
M185150/230W6.34" X 8.19" X 0.81"161.04mm X 208.03mm X 20.57mm115/230V 1Ø
#1:3.3V - 24V
#2:3.3V - 24V
#3:3.3V - 24V
#4:1.8V - 15V
#1:5A
#2:5A
#3:10A
#4:30A
MIL-STD-810, MIL-STD-461
Three Phase Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M391300W6" X 5.49" X 1.25"152.4mm X 139.37mm X 31.75mm115V 3Ø
#1:5V
#2:3.3V
#3:8.5V
#4:8.5V
#5:13V
#6:13V
#7:5V
#1:15A
#2:6A
#3:6.5A
#4:2A
#5:9A
#6:3A
#7:2.5A
MIL-STD-810, MIL-STD-461
M1156500W5.67" X 3.5" X 1.18"144.02mm X 88.9mm X 29.97mm115V 3Ø
5V - 50V
25A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M1158500W6.1" X 3.8" X 1.18"154.94mm X 96.52mm X 29.97mm115V 3Ø
5V - 50V
25A
MIL-STD-810, MIL-STD-461
M2701500W6.5" X 4.39" X 1.18"165.1mm X 111.51mm X 29.97mm115V 3Ø
100V - 320V
5A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M1831000W6.44" X 3.7" X 1.5"163.58mm X 93.98mm X 38.1mm115V 3Ø
5V - 50V
42A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M31101000W7.89" X 5.6" X 3.3"200.41mm X 142.24mm X 83.82mm115V 3Ø
5V - 50V
40A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M27051500W14.88" X 9.12" X 1.96"377.95mm X 231.65mm X 49.78mm115V 3Ø
270V
5.5A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M2861500W8.86" X 6.3" X 1.9"225.04mm X 160.02mm X 48.26mm115V 3Ø
12V - 48V
54A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M1671600W7.23" X 4.21" X 1.72"183.64mm X 107.01mm X 43.69mm115V 3Ø
3.3V - 50V
55A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M1862000W7.52" X 5.81" X 1.6"191.01mm X 147.57mm X 40.64mm115V 3Ø
5V - 60V
80A
MIL-STD-810, MIL-STD-461
M22862000W9.6" X 7.5" X 2.3"243.84mm X 190.5mm X 58.42mm115V 3Ø
12V - 36V
72A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M27032500W6.35" X 5.71" X 1.56"161.29mm X 145.03mm X 39.62mm115V 3Ø
100V - 320V
20A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M28032500W9.8" X 6.42" X 1.6"248.92mm X 163.07mm X 40.64mm230V 3Ø
100V - 320V
20A
MIL-STD-810, MIL-STD-461
M92033200W13.84" X 6.34" X 4.07"351.54mm X 161.04mm X 103.38mm440V 3Ø
24V - 80V
110A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-461
M92043200W17.19" X 6.34" X 5"436.63mm X 161.04mm X 127mm440V 3Ø
24V - 80V
110A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-461
M92053600W14" X 6.34" X 4.5"355.6mm X 161.04mm X 114.3mm440V 3Ø
270V - 360V
13.5A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-461
Two Outputs
M91490W4.92" X 3.15" X 1.5"124.97mm X 80.01mm X 38.1mm115V 3Ø
#1:5V - 28V
#2:-12V - 28V
#1:13A
#2:6.5A
MIL-STD-810, MIL-STD-461
Five Outputs
M191300W6" X 5" X 1.25"152.4mm X 127mm X 31.75mm115V 3Ø
#1:3.3V - 12V
#2:3.3V - 12V
#3:3.3V - 24V
#4:3.3V - 28V
#1:15A
#2:10A
#3:4A
#4:4A
#5:9A
MIL-STD-810, MIL-STD-461
2U Rackmount
Three Phase Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
One Output
M54808kW 440V 3Ø
150V - 350V
5 to 25AmpA
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-461
M92013600W17" X 19" X 3.47"431.8mm X 482.6mm X 88.14mm440V 3Ø
48V - V
75A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
AC+DC-DC Power Supplies
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M1467340W6.3" X 9.17" X 1.18"160mm X 233mm X 30mm90-265V
#1:2.5V - 50V
#2:2.5V - 50V
#3:2.5V - 50V
#4:2.5V - 50V
#5:2.5V - 50V
#1:25A
#2:16A
#3:18A
#4:6A
#5:4A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M7242500W8.99" X 4.99" X 1.82"228.35mm X 126.75mm X 46.23mm115/230/28V
12V - 36V
20A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
DC-AC Inverters
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M52521VA9.71" X 6.5" X 1.81"246.63mm X 165.1mm X 45.97mm22V
115V - 230V
1Ø
8.6A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M6242100VA4.2" X 4.6" X 1.4"106.68mm X 116.84mm X 35.56mm28V
26V - 115V
2.3A
MIL-STD-810, MIL-STD-461
M4252350VA7" X 6.5" X 0.85"177.8mm X 165.1mm X 21.59mm28V
75V - 115V
3.5A
MIL-STD-810, MIL-STD-461
M7032 1000VA10.63" X 4" X 5.5"270mm X 101.6mm X 139.7mm28DCV
115V - V
1Ø
8.7A
MIL-STD-704, MIL-STD-810
VITA 62 VPX SOLUTIONS
VPX with Integrated Holdup
AC Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Power Supply Outputs
M47061146W6U, 1.18"6U, 1.18"115V 3Ø
#1:12V
#2:aux 3.3V
#3:opt 12V
#4:opt -12V
#1:90A
#2:20A
#3:1A
#4:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
DC Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Power Supply Outputs
M4012350W3U, 1"3U, 1"28V
#1:12V
#2:3.3V
#3:5V
#4:aux 12V
#5:aux -12V
#6:aux 3.3V
#1:20A
#2:5A
#3:12A
#4:1A
#5:1A
#6:5A
MIL-STD-1275, DEF Stan 61-5 , MIL-STD-704, MIL-STD-810, MIL-STD-461
M4440370W3U, 1"3U, 1"28V  MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
Holdup Unit Outputs
M4262800W3U, 0.97"3U, 0.97"270V
270V
A
MIL-STD-704, MIL-STD-461
VPX 3U
AC Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Power Supply Outputs
M4071800W3U, 1"3U, 1"115V 3Ø
#1:28V
#2:3.3V
#1:30A
#2:0.4A
DC Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Power Supply Outputs
M4050150W3U, 0.8"3U, 0.8"28V
#1:12V
#2:3.3V
#3:5V
#4:aux 3.3V
#5:aux -12V
#1:2A
#2:15A
#3:12A
#4:1A
#5:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M4012350W3U, 1"3U, 1"28V
#1:12V
#2:3.3V
#3:5V
#4:aux 12V
#5:aux -12V
#6:aux 3.3V
#1:20A
#2:5A
#3:12A
#4:1A
#5:1A
#6:5A
MIL-STD-1275, DEF Stan 61-5 , MIL-STD-704, MIL-STD-810, MIL-STD-461
M4013350W3U, 1"3U, 1"28V
#1:12V
#2:3.3V
#3:5V
#4:aux 12V
#5:aux -12V
#6:aux 3.3V
#1:20A
#2:5A
#3:12A
#4:1A
#5:1A
#6:5A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M4440370W3U, 1"3U, 1"28V  MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M2192600W3U, 1"3U, 1"28V
#1:12V
#2:3.3 AUXV
#1:50A
#2:15A
MIL-STD-1275, MIL-STD-704, MIL-STD-461, SOSA™
M4365600W3U, 1"3U, 1"28V
#1:12V
#2:3.3V
#3:5V
#4:aux 3.3V
#5:aux 12V
#6:aux -12V
#1:30A
#2:20A
#3:30A
#4:5A
#5:1A
#6:1A
MIL-STD-1275, DEF Stan 61-5 , MIL-STD-704, MIL-STD-810, MIL-STD-461
M4465600W3U, 1"3U, 1"28V
#1:12V
#2:3.3V
#3:5V
#4:aux 3.3V
#5:aux 12V
#6:aux -12V
#1:30A
#2:20A
#3:30A
#4:5A
#5:1A
#6:1A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M4054800W3U, 1"3U, 1"28V
#1:12V
#2:aux_3.3V
#1:64A
#2:15A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
M4094 800W3U, 1"3U, 1"270V
#1:12V
#2:aux_3.3V
#1:64A
#2:15A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
M4154 800W3U, 1.47"3U, 1.47"28V
#1: V - 12V
#2:V - 3.3V
#3:V - 12V
#1:64A
#2:15A
#3:64A
MIL-STD-1275, DEF Stan 61-5 , MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
Holdup Unit Outputs
M4262800W3U, 0.97"3U, 0.97"270V
270V
A
MIL-STD-704, MIL-STD-461
VPX 6U
AC Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Power Supply Outputs
M40691000W6U, 1"6U, 1"115V 1Ø
#1:12V
#2:5V
#3:aux 3.3V
#4:aux 12V
#5:aux -12V
#1:50A
#2:25A
#3:25A
#4:1A
#5:1A
MIL-STD-810, MIL-STD-461
M47001000W6U, 1.2"6U, 1.2"115acV 3Ø
#1:12VV
#2:12VV
#3:5VV
#4:3.3V auxV
#5:12V auxV
#6:12V auxV
#1:0 to 30AA
#2:0 to 30AA
#3:0 to 30AA
#4:0 to 20AA
#5:0 to1AA
#6:0 to 1AA
M47051100W6U, 1.18"6U, 1.18"115V 3Ø
#1:12V
#2:aux 3.3V
#3:opt 12V
#4:opt -12V
#1:105A
#2:30A
#3:1A
#4:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
M47061146W6U, 1.18"6U, 1.18"115V 3Ø
#1:12V
#2:aux 3.3V
#3:opt 12V
#4:opt -12V
#1:90A
#2:20A
#3:1A
#4:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
M40671200W6U, 1"6U, 1"115V 3Ø
#1:12V
#2:12V
#3:5V
#4:aux 3.3V
#5:aux 12V
#6:aux -12V
#1:35A
#2:35A
#3:40A
#4:15A
#5:1A
#6:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, RTCA-DO160
M41671200W 115V 3Ø
M47011200W6U, 1"6U, 1"115V 3Ø
#1:12V
#2:aux 3.3V
#3:opt 12V
#4:opt -12V
#1:100A
#2:30A
#3:1A
#4:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
DC Inputs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
Power Supply Outputs
M4468900W6U, 1.6"6U, 1.6"28V
#1:12V
#2:12V
#3:5V
#4:aux 3.3V
#5:aux 12V
#6:aux -12V
#1:40A
#2:40A
#3:12A
#4:12A
#5:1A
#6:1A
MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
M40901200W6U, 1"6U, 1"270V
#1:12V
#2:12V
#3:12V
#4:3.3V
#5:12V
#6:-12V
#1:35A
#2:35A
#3:40A
#4:15A
#5:1A
#6:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, RTCA-DO160
M42681200W6U, 1"6U, 1"28V
#1:12V
#2:12V
#3:5V
#4:aux 3.3V
#5:aux 12V
#6:aux -12V
#1:40A
#2:40A
#3:12A
#4:12A
#5:1A
#6:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M4703 1200W6U, 1"6U, 1"270V
#1:12V
#2:aux 3.3V
#3:opt 12V
#4:opt -12V
#1:105A
#2:30A
#3:1A
#4:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
M47071200W6U, 1.18"6U, 1.18"270V
#1:12V
#2:aux 3.3V
#3:opt 12V
#4:opt -12V
#1:100A
#2:30A
#3:1A
#4:1A
MIL-STD-704, MIL-STD-810, MIL-STD-461, SOSA™
Uninterruptible Power Supplies
1U Rackmount
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M10121.25kW19" X 24" X 1.72"482.6mm X 609.6mm X 43.69mm115/230V 1Ø
115V - V
11A
MIL-STD-704, MIL-STD-810, MIL-STD-461, RTCA-DO160
3U Rackmount
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M1201kW19" X 28" X 5.25"482.6mm X 711.2mm X 133.35mm115/230V
112V - 118V
8.7A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
M359-12.0kW19" X 22" X 5.2"482.6mm X 558.8mm X 132.08mm115V 1Ø
112V - 118V
17.4A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-167, MIL-STD-461
M359-22.0kW19" X 22" X 5.2"482.6mm X 558.8mm X 132.08mm115V 1Ø
112V - 118V
17.4A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-167, MIL-STD-461
M359-32.0kW19" X 22" X 5.2"482.6mm X 558.8mm X 132.08mm115V 3Ø
112V - 118V
17.4A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-167, MIL-STD-461
M3622.5kW19" X 18.25" X 5.2"482.6mm X 463.55mm X 132.08mm115/230V 1Ø
#1:110V - 120V
#2:110V - 120V
21.7A
MIL-STD-1399, MIL-STD-810, MIL-DTL-901, MIL-STD-167, MIL-STD-461
4U Rackmount
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M1101kW19" X 21" X 6.9"482.6mm X 533.4mm X 175.26mm115/230V
112V - 118V
8.7A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
M1301.5kW19" X 21" X 6.9"482.6mm X 533.4mm X 175.26mm115/230V
112V - 118V
13A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
M1402kW19" X 21" X 6.9"482.6mm X 533.4mm X 175.26mm115/230V
112V - 118V
17.4A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
GCU Power Supplies
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M7049400W3.62" X 3.69" X 1.65"91.95mm X 93.73mm X 41.91mm28V
24V - 50V
26.785A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M495600W4.53" X 3.94" X 1.57"115mm X 100mm X 40mm115V 3Ø
24V - 50V
25A
MIL-STD-704, MIL-STD-810, MIL-STD-461
M27812800W9.84" X 7.09" X 4.33"250mm X 180mm X 110mm115V 3Ø
39V - 200V
100A
MIL-STD-704, MIL-STD-810, MIL-STD-461
Accessories
Battery Chargers
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M346-1  115V
Battery Packs
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M333-4 19" X 22" X 3.5"482.6mm X 558.8mm X 88.9mm108V  MIL-STD-810, MIL-DTL-901, MIL-STD-461
EMI Filters
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M1987300W4.18" X 3.97" X 1.34"106.15mm X 100.71mm X 34.04mm115V 1Ø
85V - 265V
5A
MIL-STD-1399, MIL-STD-810, MIL-STD-461
M4916500W4.61" X 1.8" X 1.18"117.1mm X 45.7mm X 30mm115V 1Ø
#1:85V - 265V
#2:103V - 127V
#1:10A
#2:10A
MIL-STD-810
M32892000W5.91" X 2.56" X 1.34"150.11mm X 65.02mm X 34.04mm115V 3Ø  MIL-STD-704, MIL-STD-810
Voltage Suppression
SeriesPowerDimensionsInput VOutput VMax. Curr.Designed to Meet
M1020 3.63" X 3.93" X 1.9"92.3mm X 99.9mm X 48.2mmV

Bel Aerospace & Defense

P: +49 4261 9429979

Sales office:

Amelia-Mary-Earhart-Str. 8
60549 Frankfurt am Main
Germany

This email address is being protected from spambots. You need JavaScript enabled to view it.

Categories
About Us Contact SupportMarketingNewsletterBel Fuse, Inc
© 2026 Bel Aerospace & Defense | International Military Power and Communication Solutions
Created by Mark Media Group
